=======Belkin Wireless router Setup for Ragnarok Server 1.0
=======
=============================================
Steps to be done
=============================================
1.) First you need to follow the direct steps F.O.X has giving you on this area Link:http://forum.ragezone.com/f84/guide-...-guide-306524/
Follow the steps closely and make no mistakes, its very clear how to make it run, That means to
Have a Full patched RO / Sak client, (if your having trouble patching go here to learn how to manual patch, I advice you to do it this way anyways, http://forum.ragezone.com/f84/guide-...sakray-322054/).
===
2.) After getting that all set-up clearly, Your SQL, Eathena, Client, X-ray hexed exe, and your data files are all proper, and working on que, no errors loading, or connection issues. (your server will still run on ur computer still with a router going, but no one will be able to connect, but you.) Goto C:\programfiles\Gravity\Ro\Data <-- the folder that was told to make it has your sclinetinfo.xml in it, We need to right click that file and edit. when you edit it make sure u make it look like this.
<?xml version="1.0" encoding="euc-kr" ?>
<clientinfo>
<servicetype>korea</servicetype>
<servertype>sakray</servertype>
<connection>
<display>AaronRserveR</display>
<desc>None</desc>
<address>127.0.0.1</address> <-- this port is your offline port *(most of the time)*.. (be sure when you get this done, if you want others to join to change it to your Wan-ip, which is said inside ur router connections
<port>6900</port>
<version>20</version>
<langtype>8</langtype>
<registrationweb></registrationweb>
<yellow>
<admin></admin>
</yellow>
</connection>
</clientinfo>
okay Save that edit, and double click your X-ray (hexed exe).exe and login, should work fine, Note: i had to change it to wan-ip after i fixed up my router. (Test ur game, walk around, enjoy it for a momment, learn it a second, learn your gm codes and all that stuff, Then will move on).
========
3.) Setting up that evil router.. okay for though who dosnt know, You can enter you (Router by using your explore) for example to enter, u put in the correct ip of your router. which if u got a lil icon on ur lower right hand corner in the startup bar, double click it, it'll pop up ur wireless connection screen click on support and look for defualt gateway. 198.xxx.x.x number. (place that into your Explore bar) it should connect u to your router. (i put pictures up asap for more example). okay first , you need to click on is:
1._ Click on firewall, and disable it. (most importent).
2._ Now we need to goto ether (port forwarding or Virtual Servers) - depends on your router. (ill edit and put picture link here)
3._ Now were going to follow the steps f.o.x gave us..
= Router Guide, Port forward
=Notice: If you dun have any Router or IP block system, you can skip this step.
=1. Once you get into your router configuration page, either on top of on the right, there should be a link saying port fowarding. After = accessing into this page, create a new service each one named char, map and login.
=2. For login, foward ports FROM 6900-6900, which means start port-6900 and end port-6900 and server ip address is your "LAN IP"
=3. For char, foward ports FROM 5121-5121. which means start port-5121 and end port-5121 and server ip address is your "LAN IP"
=4. For map, fowards ports FROM 6121-6121. which means start port-6121 and end port-6121 and server ip address is your "LAN IP"
=5. Make sure all is TCP not DCP.
============Note If your on a Belkin in Virtual servers, u will havta put it like this =====
= enable, -desciption- , inbound port, type, private ip [last number of ur Ip designed ie 192.168.1.0 would connect to router 192.168.1.2 is = yours), Private port will be on your screen.
= check 3 boxes for enable
= in desciption in the boxes right char, login, map
= in inbound port put : char 5121/ 5121 Do the same in the (Private port) for each one enabled
login 6900/6900
map 6121 /6121
= last put in your Private Ip (the example above
= Apply changes and lets move to step 4._
================Ill place a picture link here when i edit==============================
= Now lets move on
==============
4._ Last step for this (in belkin setup or router setup find dmz options)
You will need to enable it. It'll look like this in screen
== Example in belkin router (ill add picture here next update)
== Static IP Private IP Enable [x] <- check box
==1. 71.xx.89.xxx 192.168.2. [0] this box is empty you need to put ur last digit of ur Lan/ip (private ip address)
== Apply changes, and close out your explorer.
==Moving on
==
==Last step====
5._ Okay now, thats all tookin' care of, lets go back to your c:\programfiles\gravity\ro\data - sclinetinfo.xml (edit it and put ur wan/ip) You can get your wan ip, off your router connections inside where we setup, should be on front page) (ill place picture here for that). Save file. Launch your Mysql, Eathena bat files, and xray client, Login in and it should get you there.
===end====
Any question post here for this. I did my best, and i wish you all good luck.
TalonStart
