(Live) VBOX Bridging for over net play (Ronny1982 / Hrace009)

This is a simple tutorial to get your vbox live to the net so people outside your network can play on your server

This is more directed towards Ronny1982 VBOX PWServer on hrace009 page http://forum.ragezone.com/f452/vbox-...-1-3-a-650130/

i see alot of posts about getting that live so here is a tutorial

MAKE SURE NO OTHER SYSTEM IS USING THAT IP

HAVE YOUR SERVER OFF AT THIS POINT

\\\STEP 1\\\

Put your Vbox into Bridge Mode
Select the PWServer-hrace009 system
go to Settings (gold Gear) on the start up area
Go to Network
if not already activate check "Enable Network Adapter"
Attached to "Bridged Adapter"
Name "Select the device your getting internet from"

Click the Advanced arrow

Adapter Type: "PCnet-FAST III (Am79C973)"
Mac Address: "080027AD81AD"

and make sure you have enabled "Cable Connected"

!!!!!!!!!!!!For Latest Version of VBox!!!!!!!!!!!!!!!!!!!!
there is word that you can also use NAT and enable the port forwarding that way.
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!


\\\STEP 2\\\

in your VBOX type in terminal ifconfig

Link encap:Ethernet HWaddr 08:00:27:ad:81:ad
inet addr:192.168.0.10 the rest after this doesnt matter
its the ip and the mac address you need

Now as it is a Bridged Server you need to open the ports on your firewall.

Alot of people get confused thinking its just the servers IP or the computer's IP, YOU HAVE TO PUT BOTH

example
Vbox server is 192.168.0.10
Computer running Vbox is 192.168.0.30

and add these ports 80 8080 29000 to both 192.168.0.10 AND 192.168.0.30

YOU MUST HAVE BOTH IP's registered with those ports

add those to your firewall as well

go to your Router http://192.168.0.1 enter your username and password

there is 2 ways of doing this.

DMZ your computer example 192.168.0.30 and enable the DMZ

Now Port Forward your server in your Port Forward area

if your server is not running 192.168.0.10 use the ip it provides
can sometimes be 192.168.0.51 but as i said this is for ronny1982 / hrace009 page and the ip is set to 192.168.0.10

TCP 29000 192.168.0.10 enable it
TCP 8080 192.168.0.10 enable it
TCP 80 192.168.0.10 enable it

Should work

OR you can if your router will allow you too is multiple forwards and you wont have to use DMZ

TCP 29000 192.168.0.30 enable it
TCP 8080 192.168.0.30 enable it
TCP 80 192.168.0.30 enable it
TCP 29000 192.168.0.10 enable it
TCP 8080 192.168.0.10 enable it
TCP 80 192.168.0.10 enable it


hope this makes sence to everyone i was playing around and found out how to work the VBox

IF YOUR RUNNING AN SMC ROUTER THERE IS A LITTLE MORE CHALLENGE TO GET PORT FORWARDING TO WORK

if I have missed anything let me know


ANOTHER THING... if your using canyouseeme.org to see if the ports are open, they will not show until you start the server from 192.168.0.10:8080/pwAdmin then it will become live to the net


\\\PROBLEM WITH IP, YOU CAN CHANGE IT\\\

Quote:

---

Originally Posted by hrace009

change your VBOX Network Interface /etc/network/interfaces

# This file describes the network interfaces available on your system
# and how to activate them. For more information, see interfaces(5).

# The loopback network interface
auto lo
iface lo inet loopback

# The primary network interface
auto eth0
iface eth0 inet static
address YOUR VBOX IP
netmask YOUR NETMASK
network 172.16.0.0 <<< Always Fill This XXX.XXX.0.0
broadcast YOUR NEWORK BRODCAST
gateway YOUR GATEWAY IP TO INTERNET
# dns-* options are implemented by the resolvconf package, if installed
dns-nameservers YOUR DOMAIN IP, IF YOU USE DOMAIN
dns-search YOUR DOMAIN NAME, IF YOU USE DOMAIN

-----------------------------------------------------------------
and don't forget to Replace the IPs with your current addresses except the lines with 0.0.0.0

/PWServer/gacd/gamesys.conf
/PWServer/gamed/gmserver.conf
/PWServer/gamed/gs.conf
/PWServer/gamed/gsrollback.conf
/PWServer/gamedbd/cashstat.conf
/PWServer/gamedbd/gamesys.conf
/PWServer/gdeliveryd/gamesys.conf
/PWServer/gfactiond/gamesys.conf
/PWServer/glinkd/gamesys.conf
/PWServer/logservice/logservice.conf
/PWServer/uniquenamed/gamesys.conf
/etc/authd.conf
/etc/gmopgen.xml
/etc/GMserver.conf
/etc/hosts
/etc/iweb.conf

---

wow, nice tutorial i will try it on my Server :thumbup:

alright let me know if this also works for you. worked for me like a charm.

i have the VBOX running my server online right now, seems to hold up very well.

---------- Post added at 08:41 AM ---------- Previous post was at 08:39 AM ----------

i had so many problems with it saying an ip conflict that i relized my iphone was using that ip so if you have one change the ip on your apple device. for some reason it sets itself to 192.168.0.10 if you need help with that i can help too lol

nice, thx for info.
But do u know if that release is better than another one?
I'm trying it and have a lot of bugs QQ

what kind of bugs are you having with your VBox

hhahaa, no bugs with Vbox, its easy to use. Only on server, but may its because i have changed some files. ^^
I have to keep working few more time on it.
Thx for ur guide dude, is easier and work fine ;)

P.S: was asking if exist a better release than ronny's hracer's release

im using that same very one and its live and running ive got friends on it all the time.

what is it thats going on with the version you have

Maps (instances) crash when u kill any mob (only if u are in a party it happens)
Already did a th about it, I'm waiting for any reply xD

is that just for you or anyone that uses it... wait have you got it live yet? it might just be your client

no yet QQ only in my lan network.
But it's simple, when u enter in a instance with another party member u get a quest (trophy mode) or sumthing like that. And if u kill any mob, map get crashed. Its because "party counter" from 1.4.2 it dont exist in 1.3.6. I guess is that, but I'm not sure. I'm just starting on PW server dev.

ya i havent actually tried trophy mode, your refering at the gate or wraith / wraithgate right?!

if you get it live let me know ill message you an email so you can send your ip or no-ip route and ill join in and see if its clientside or server...

does the Server actually crash or does your client just close?!

No, only map get crashed, for example: U and a mate go to... TT or Brimstone, u kill a mob and, before it die, the map get crashed.
Trophy mode quest its a pop-up, may i have to delete it :(

hmmm. i sent you a couple Private messages

ALSO how many maps are you running at once

sure dude, let me get pw files in this computer. :)

alright well i gotta go its 6:41 am here gotta sleep ill be back in a couple hours

oohh, well! that was happening xD Server is offline xD was trying many ways to conecting lol

i see you registered and i guess your client differs from mine which is odd we both have the save version of the vbox hrace 009

---------- Post added at 08:03 PM ---------- Previous post was at 08:00 PM ----------

did you load the proper elements.data and gshop.data to your server & Client

i had so many problems with putting this server online that now it works i fear it can go bug again :S
I need the server to work just for 10 or less friends so i guess i need to make it public. last time i tryed was with the no-ip thing but didnt work and bugged all server(finally fixed ) so my msn is :petkris_bg@hotmail.it
would love if u could teach me via teamviewer :):) would really really apreciate your help :)

oh its incredibly easy but sure ill go on teamviewer now ill add you to msn

---------- Post added at 09:39 PM ---------- Previous post was at 09:27 PM ----------

i added you

I use DSL the modem.
I can not play with friends! Please show video the instruction or detailed screenshots. 2 days don't sleep any more - I will become crazy soon O_o

Forgive for my English - I Russian

i'm confused with this tutorial, because i don't use a router to connect to internet

go to command prompt and type ipconfig
you should see an id as 192.168.x.x then you are on a router/modem

its its like 24.88.123.554 or something like that then your on direct net

-edited-

alright i added you to msn

wow i think ive become a master to this VBOX lol. and routers. omg theres some tough ones out there

Quote:

---

Originally Posted by Naxer

I use DSL the modem.
I can not play with friends! Please show video the instruction or detailed screenshots. 2 days don't sleep any more - I will become crazy soon O_o

Forgive for my English - I Russian

---

do you have teamviewer or anything. i can help you set your server up. and your english is fine.

i can do it for you if you would like.

Quote:

---

Originally Posted by 88supra86

do you have teamviewer or anything. i can help you set your server up. and your english is fine.

i can do it for you if you would like.

---

hey, i have teamvewer, can you help me to config my server ?:/:

ya i can whats your msn or skype

Quote:

---

Originally Posted by 88supra86

do you have teamviewer or anything. i can help you set your server up. and your english is fine.

i can do it for you if you would like.

---

I have established TeamViewer when we will communicate?
For correspondence, it is possible to use Skype (nickname: Naxer007).
Thanks!

ok whats your skype address i will add you

---------- Post added at 09:58 AM ---------- Previous post was at 09:17 AM ----------

Quote:

---

Originally Posted by CULOBG

i had so many problems with putting this server online that now it works i fear it can go bug again :S
I need the server to work just for 10 or less friends so i guess i need to make it public. last time i tryed was with the no-ip thing but didnt work and bugged all server(finally fixed ) so my msn is :petkris_bg@hotmail.it
would love if u could teach me via teamviewer :):) would really really apreciate your help :)

---

well now your servers working how is it going

I can't adjust the server, for game with friends.
I have TeamViewer.
My Skype: Naxer007
Help me please :*:

what do you mean you cant adjust the server.... ill help you

do you have MSN Messenger my skype doesnt work anymore for some reason.

Sorry for the late reply was busy this week

i have tried this method so many times but once i bridge my adapter on vbox, i lose all connection to the PWAdmin, thus i cant start my server :P please help if possible :*:

PS: i have my IP settings on my adapter (PC) on Obtain Automatically as i dont know what my Gateway IP would be..if i was to put a IP address in there.. cheers

try disabling the host only adapter in your network settings through control panel. then on vbox put it to bridged

type ifconfig in vbox make sure to use that ip

let me know if this helped

Quote:

---

Originally Posted by 88supra86

try disabling the host only adapter in your network settings through control panel. then on vbox put it to bridged

type ifconfig in vbox make sure to use that ip

let me know if this helped

---

Ok i disabled the host only network via windows, alas i still cant get to PWadmin to start the server, it works fine with the host only set up,but no access from the outside to my server, and i also set vbox to bridge the network and i have more ports open on my router that a shipyard atm lol and port forwarding from my pc x.x :(:

you should also post that this shouldnt be used as a real server considering the 0 security this has, everything is public if you set everything to your public ip, you only want people connecting to the glinkd, everything else should be 127.0.0.1.
i know people with enough experience can inject packets to crash specific services that are public

thats true

also you should be able to access your pwAdmin from your machine by 192.168.0.10 even if its bridged did you change the files to the ip you need
if your on a system that gives 192.168.1.* you will need to change the ip's in all the files that should be posted on the first page

Quote:

---

Originally Posted by 88supra86

thats true

also you should be able to access your pwAdmin from your machine by 192.168.0.10 even if its bridged did you change the files to the ip you need
if your on a system that gives 192.168.1.* you will need to change the ip's in all the files that should be posted on the first page

---

All my setting are set to 192.168.0.10 thats what i found in the files mentioned on the first page, asides the ones with 0.0.0.0, and thank you for the warning regarding security as im new to this that is great advice ty:): no i cant reach iweb if im bridged, but i do have no-ip on my system is there a way i can utilize that as its not installed on my server, but it is on windows? i have read the no-ip thread but they have that installed on there server, and i checked and its not on mine lol

add me on MSN sam-763@hotmail.com i have many problems :( i want play with my friends

hello can you help me too i wanna play with my friends add my msn:cosminx13@gmail.com

bro, i am using 343's server files. i set all IP on
/etc/hosts
/opt/lampp/htdocs/config.php
/opt/apache-tomcat-5.5.28/2/webapps/pwAdmin/addons/Maskgen/index.jsp

to 127.0.0.1 will it work for friends to play with?
and i have DMZ to my lAN"s IP and opened ports my server's IP.
but 343 said it needs to be WAN IP on
/etc/hosts
/opt/lampp/htdocs/config.php
/opt/apache-tomcat-5.5.28/2/webapps/pwAdmin/addons/Maskgen/index.jsp

it's fine or i need to change all the IP on
/etc/hosts
/opt/lampp/htdocs/config.php
/opt/apache-tomcat-5.5.28/2/webapps/pwAdmin/addons/Maskgen/index.jsp
to WAN?

I am getting confused about this part

Now as it is a Bridged Server you need to open the ports on your firewall.

Alot of people get confused thinking its just the servers IP or the computer's IP, YOU HAVE TO PUT BOTH

example
server is 192.168.0.10
Computer is 192.168.0.30

do you mean, we need to add 29000,8080,80 with both IP address to our firewall? i am using basic winxp firewall and it won't let me add both IP with the same ports lol.

Quote:

---

Originally Posted by john007

bro, i am using 343's server files. I set all ip on
/etc/hosts
/opt/lampp/htdocs/config.php
/opt/apache-tomcat-5.5.28/2/webapps/pwadmin/addons/maskgen/index.jsp

to 127.0.0.1 will it work for friends to play with?
this is wrong sould be your lan ip exammple 192.168.0.123 or whatever your lan ip is

and i have dmz to my lan"s ip and opened ports my server's ip.
But 343 said it needs to be wan ip on
again wrong. 343 is right. But if your using vbox you want to set your pc's ip ports and put your vbox to dmz (this will not open unwanted ports that your pc doesnt have open

/etc/hosts
/opt/lampp/htdocs/config.php
/opt/apache-tomcat-5.5.28/2/webapps/pwadmin/addons/maskgen/index.jsp

it's fine or i need to change all the ip on
/etc/hosts
/opt/lampp/htdocs/config.php
/opt/apache-tomcat-5.5.28/2/webapps/pwadmin/addons/maskgen/index.jsp
to wan?

again you want your ip's to be your lan ip address not 127.0.0.1 only local address should be that address

i am getting confused about this part

now as it is a bridged server you need to open the ports on your firewall.

yes if you open the 2900 8080 80 to your pc's ip and put dmz on your vbox you will be fine.

alot of people get confused thinking its just the servers ip or the computer's ip, you have to put both
yes both ip's need to be added. Dont know why but it does... 1 your running a vbox from your pc machine (needs ports) then you run a vbox thats considered a new pc running through your pc so you need to open the ports on the vbox too.

example
server is 192.168.0.10 -yes this is correct. You cannot match this ip with pc because they are considered 2 different systems. (if you make them the same you will get conflict
computer is 192.168.0.30

do you mean, we need to add 29000,8080,80 with both ip address to our firewall? yesi am using basic winxp firewall and it won't let me add both ip with the same ports lol because thats windows xp... Your server is ubuntu (assuming).

---

you need to add the port forwards to your router.... Example 192.168.0.1 or 192.168.1.254 TO ACCES YOUR ROUTER.

SUGGEST A PROGRAM FOR ME TO USE TO MAKE A VIDEO TUTORIAL

i am still don't get this why put LAN's IP on
/etc/hosts
/opt/lampp/htdocs/config.php
/opt/apache-tomcat-5.5.28/2/webapps/pwadmin/addons/maskgen/index.jsp

but not my WAN IP which is at whatismy.com?

and what PC's IP ports are you talking about? im so confused here. maybe you can help me setup through team view bro? i will add you on my MSN.

Quote:

---

Originally Posted by john007

i am still don't get this why put LAN's IP on
/etc/hosts
/opt/lampp/htdocs/config.php
/opt/apache-tomcat-5.5.28/2/webapps/pwadmin/addons/maskgen/index.jsp

but not my WAN IP which is at whatismy.com?

and what PC's IP ports are you talking about? im so confused here. maybe you can help me setup through team view bro? i will add you on my MSN.

---

because its creating a address for the files in that ip (which is your machine)

in htdocs/config.php you would want to put your wan ip, so that the public can view that page and then everything should all connect together

Thanks to 343 for the PW complete pack, Drakaer and 88supra86 for all the guides. I finally made it work! I just reinstalled PW to vbox and entered the values of my local ip and wan ip. Without your help guys I wouldn't be able to do it. Now, I'm testing it. :D So happy!

I just have one question though:

How can I edit the database? My prob is I can't edit it because it's just mounted via virtual disc (magicISO). I extracted the content to a folder in my desktop but I dunno if it is possible to assign vbox to use the one in my desktop instead of the one mounted via virtual disk (MagicISO)??? Pls help T_T

Here's a link of the video

Code:

---

http://www.youtube.com/watch?v=K93bMw47zdM

---

Glad you got it working.

If you followed 343's guide it is already on your computer.

In 343's guide you mount the iso and run

Code:

---

mount /dev/cdrom /cdrom
 cd /cdrom
 cp -R * /

---

What this does is copy the contents of the disc to your virtual harddrive. So you already have the server files on your vbox hdd. I'm sure you already did this though otherwise you wouldn't have been able to change the config files.

So to edit the exp rate like you were trying to do you start vbox (dont start the server yet). Then you type

Code:

---

nano /PWServer/gamed/ptemplate.conf

---

then you can edit it just like you did with interfaces.

If you prefer a GUI approach the you can use winscp or an ftp client.
WinSCP :: Free SFTP and FTP client for Windows
You may need to install openssh first by running

Code:

---

apt-get update
apt-get install openssh-server

---

Once you have done that you login to winscp using the login, password and ip of your server. It then brings up a file manager where you can browse to ptemplate.conf and right click the file and edit it. you can also transfer files to and from your windows and vbox machines.

Also you may find Notepad++ better than M$ Word for editing perfect world files in.
Notepad++ Home

Wow!♥ You never fail to amaze me sir Drakaer! This simple things mean a lot to me. Thanks a lot for always being there to help newbies like me. I really appreciate your being very assistive! I'll try them tomorrow when my girlfriend goes out. She's here now and she doesn't want me to play.... so I'll play with her tonight. :thumbup:

Currently, I'm using nano /PWServer/gamed/ptemplate.conf on vbox terminal bcoz ryt now, it's much easier for me. :D

By the way, are there 3 classes only? No Tideborn and earthguard?

There are 6 classes, 3 races. Its impossible currently to have tideborn and earthguard.

I don't see much point in having them anyway. Age of spirits is the best in my opinion.

Oh! Got confused with the terms there @_@
Yah age of spirits really is the best bec it's what got me playing for so long! Now, a lot has changed.

Ahm maybe tideborns and earthguards have different skills, styles, etc? & my friends wanna try them also. They say it's kinda "cool". lol. It's fine if we don't have them yet. We're still hoping that someday, they would be added also :D

By the way, I just wanna ask if it is possible to put stones to Rank IX gears? They don't have "slots" for stones. Where could we edit that? Tried to search in the client the word "socket" but nothing appeared... I wish I knew where to find things.

Depends how you want to add them.

If you are buying from the boutique I don't think they have sockets. If you craft them then you can add sockets in the elements.data

You can also buy the item and edit the hex data of the item via pwadmin. You basically change to xml mode and copy and paste edited or generated hex.
You can use this to generate hex.
http://forum.ragezone.com/f694/item-...erator-711597/
Or you can edit existing hex by following my guide
http://forum.ragezone.com/f695/hexdata-guide-663918/

Thanks I already got some idea with the help of the pictures! I want to try them now but somebody wants me to go to bed already... *sigh* I wish I learned these stuff when I was still single. :D I'll study these tomorrow.:thumbup:

wow this page was dead for the longest time now its alive lol. thats crazy.

pzykie hopefully your server is running well now,

now to learn modifications :P google and ragezone is where you will find it :P

It's running but i always have to reinstall it because some things happen like my char can't log in or server network error pops up when I try to log in after editing my char thru pw admin. I just added a coin like 250,000,000 thru pwadmin and after that my char can't enter pw anymore coz world 1 auto-stops... I am currently reinstalling the server now. :D We'll am getting used to it though. I feel like an expert already. ROFL. I know these things are really basic :D I'm just happy that guys here are very helpful! I'm learning a lot. You guys are awesome! :thumbup:

You don't have to reinstall your server every time it fails.

If you add something to your character and the world map crashes then just remove what you added and it will be all fixed.

Also if you run backups you can easily revert back to the backups without reinstalling.

Quote:

---

Originally Posted by Drakaer

You don't have to reinstall your server every time it fails.

If you add something to your character and the world map crashes then just remove what you added and it will be all fixed.

Also if you run backups you can easily revert back to the backups without reinstalling.

---

this is true. if the world map crashes, go to pwAdmin and remove it. also in pocket you can only hold 200 mill

also learn about the hex editor for weapons and armor because if its done wrong you can crash the world map and have to delete the item you made

Haha. Thanks! I have learned to back up every important updates in my server

How can we build houses in PW?

Aw got an error. I just changed server time yesternight and now this appeared: http://www.fileden.com/files/2008/5/...2//fscheck.JPG

amyone knows what's causing this problem?

It says right in the message:

"LAST MOUNT TIME IS IN THE FUTURE"

-- It knows that the last time the volume was mounted was in the future... which of course is physically impossible -- It's like, "the last time I turned on my PC, was tomorrow".......

Oh I see.... That's why... Now I remembered that I changed the server time in the future i.e., August 4, 2011 last night then I changed it again to real time this morning. :D

BTW, I can't get out of hall of blasphemy. Is there any way out? I went there for the purpose of entering Hell map so that I could visit the Wizard master and learn Dark skills but I was trapped instead T_T

If you get stuck in an instance you can log out and change your position on pwAdmin to a different map. Then when you log in you will be elsewhere.

If you don't know what yo change the coords to then look at the templates and you will end up in the starter areas.

You also might be able to use teleport incense or town portal to get out.

I tried using tele incense & town portal but no effect as if nothing happened so just created a new lvl 1 char just to see the right coordinates and world #.

By the way, is Heaven and Hell accessible in 343's release?

I'm using search trying to get here -> http://i790.photobucket.com/albums/y...afterskill.png

I would just like to know why the tele for "temple of nirvana" in illusion stone at West City is in red text??? Is it included in the list of maps/instances in pwAdmin? Can't find "temple of nirvana" in the list.

Any suggestion how to get there just like in the pic?

The maps should work. Sometimes you have to give them a little bit of time to start depending on your system requirements.

I don't have 343's release installed so I don't know if they work or not but most likely they would.

Do you have the required cultivation to enter?

Up only to lvl 99 cultivation. I'll try to reach max lvl and cultivation then try again. hehe. Hope it works. I dunno what name of map (temple of nirvana not in the list of pwadmin) should be activated in pwadmin for my char to enter heaven and hell gates so I'll enable all the instances except the ones that I know is not. Thanks for the kind reply! :D

Quote:

---

Originally Posted by pzykie

Up only to lvl 99 cultivation. I'll try to reach max lvl and cultivation then try again. hehe. Hope it works. I dunno what name of map (temple of nirvana not in the list of pwadmin) should be activated in pwadmin for my char to enter heaven and hell gates so I'll enable all the instances except the ones that I know is not. Thanks for the kind reply! :D

---

If you're using my release, I have full culti :p

---------- Post added at 07:35 PM ---------- Previous post was at 07:34 PM ----------

I remember that very well, because I created the 'custom' quests to be able to get to your 3rd culti... (Celestial Sage) or (Celestial Demon)

---------- Post added at 07:36 PM ---------- Previous post was at 07:35 PM ----------

Oh, and you only need level 89 culti to get in map 21 or 22

Thanks 343! I love ragezone♥ :D

Hi everyone esp to Mods and Devs. I just wanna share some screenshots. Hex editing is fun. Drakaer's guide is very easy to follow. Nice guide! I love it!

Screenshots: :D ♥♥♥

Code:

---

http://www.fileden.com/files/2008/5/31/1937732//2011-08-06 16-05-35.bmp
http://www.fileden.com/files/2008/5/31/1937732//2011-08-06 16-05-38.bmp
http://www.fileden.com/files/2008/5/31/1937732//2011-08-06 16-05-48.bmp

---

would you be kind to post images too? lol!

pictures of what exactly. its quite strait forward. which part are you stuck on

"DMZ your computer example 192.168.0.30 and enable the DMZ". that's where I'm kinda stuck, lol.

what if your Router can only do 192.168.1.and then u can pick the numbers?
Not like 192.168.0.and then pick.
And how do you change the ip of Virtual box and the server?

88supra86 supra could u add me on skype please? i need a bit of help skype: vasy.anonim

88supra86 can u help me i have TeamViewer ,,my msn sam-761@hotmail.com :(

hey supra i would realy need your help for a few mins im stuck at something..please pm me or gget on skype...ty

Instead of saying to get on skype, maybe try posting your question here and we can help.

//facepalm

hmmmm im not useing VBOX im using VMWARE and supra helped me to set the server up and make it public...and i had a sh1ty internet provider ..now i changed my internet provide (i got way higher internet speed) and he knows perfectly how to configure all fast....the thing is that im almost done customising and i have to test and alone i cant..

ya man your net was wacked... but we got it working hopefully things are still going good foryou on your end

yea with ur huge help i had an online server...and now i changed the internet provider but i have no idea how to set up VMW and the DNS u know this perfect and if u can help me ...

88supra86 can u help me i have TeamViewer ,,my msn sam-761@hotmail.com :(

Quote:

---

Originally Posted by 88supra86

This is a simple tutorial to get your vbox live to the net so people outside your network can play on your server

This is more directed towards Ronny1982 VBOX PWServer on hrace009 page http://forum.ragezone.com/f452/vbox-...-1-3-a-650130/

i see alot of posts about getting that live so here is a tutorial

MAKE SURE NO OTHER SYSTEM IS USING THAT IP

HAVE YOUR SERVER OFF AT THIS POINT

\\\STEP 1\\\

Put your Vbox into Bridge Mode
Select the PWServer-hrace009 system
go to Settings (gold Gear) on the start up area
Go to Network
if not already activate check "Enable Network Adapter"
Attached to "Bridged Adapter"
Name "Select the device your getting internet from"

Click the Advanced arrow

Adapter Type: "PCnet-FAST III (Am79C973)"
Mac Address: "080027AD81AD"

and make sure you have enabled "Cable Connected"

!!!!!!!!!!!!For Latest Version of VBox!!!!!!!!!!!!!!!!!!!!
there is word that you can also use NAT and enable the port forwarding that way.
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!


\\\STEP 2\\\

in your VBOX type in terminal ifconfig

Link encap:Ethernet HWaddr 08:00:27:ad:81:ad
inet addr:192.168.0.10 the rest after this doesnt matter
its the ip and the mac address you need

Now as it is a Bridged Server you need to open the ports on your firewall.

Alot of people get confused thinking its just the servers IP or the computer's IP, YOU HAVE TO PUT BOTH

example
Vbox server is 192.168.0.10
Computer running Vbox is 192.168.0.30

and add these ports 80 8080 29000 to both 192.168.0.10 AND 192.168.0.30

YOU MUST HAVE BOTH IP's registered with those ports

add those to your firewall as well

go to your Router http://192.168.0.1 enter your username and password

there is 2 ways of doing this.

DMZ your computer example 192.168.0.30 and enable the DMZ

Now Port Forward your server in your Port Forward area

if your server is not running 192.168.0.10 use the ip it provides
can sometimes be 192.168.0.51 but as i said this is for ronny1982 / hrace009 page and the ip is set to 192.168.0.10

TCP 29000 192.168.0.10 enable it
TCP 8080 192.168.0.10 enable it
TCP 80 192.168.0.10 enable it

Should work

OR you can if your router will allow you too is multiple forwards and you wont have to use DMZ

TCP 29000 192.168.0.30 enable it
TCP 8080 192.168.0.30 enable it
TCP 80 192.168.0.30 enable it
TCP 29000 192.168.0.10 enable it
TCP 8080 192.168.0.10 enable it
TCP 80 192.168.0.10 enable it


hope this makes sence to everyone i was playing around and found out how to work the VBox

IF YOUR RUNNING AN SMC ROUTER THERE IS A LITTLE MORE CHALLENGE TO GET PORT FORWARDING TO WORK

if I have missed anything let me know


ANOTHER THING... if your using canyouseeme.org to see if the ports are open, they will not show until you start the server from 192.168.0.10:8080/pwAdmin then it will become live to the net


\\\PROBLEM WITH IP, YOU CAN CHANGE IT\\\

---

you can make via youtube

nope , he cant because we dont have the same internet providers , but this tutorial is easyer then it looks like when u figure out what you have to do

Can this tutorial works on laptop that use wi-fi connect with router if doesnt work can someone help me and tell me how to do it .
I use vbox on win7 os :)^^

I'm having some issues with forwarding ports on my router, is it possible that you could help me out ?

Not to be rude but, this is the PW section... We know PW better than we know any specific router. You would probably have better luck looking in your owners/users manual, or googling your routers model number + what you want to do (in this case router model# + port forwarding)... Other than that if you really wanted help here, you haven't even provided any info so that anyone could possibly help... Like the manufacturer and model#... Again (not trying to be rude but) we know PW, we are not psychics... :wink:

So, my advice:

• consult your owners/users manual (or any help menus from within your routers web based configuration area)
• consult google [google~ model# + port forwarding](If that doesn't yield any results try again w/ adding the manufacturer name {google~ manufacturer name + model# + port forwarding})
• Post the manufacturer + model# of your router here (if you want to attempt to get help from here)

:wink:

guys,can someone teach me to do port forwarding my router is TP-LINK TL-WR740N ?


P.S:Found out how,but i cannot set as IP the server IP just my LAN IP.How to fix that?
Attachment 112987

Quote:

---

Originally Posted by war351

guys,can someone teach me to do port forwarding my router is TP-LINK TL-WR740N ?


P.S:Found out how,but i cannot set as IP the server IP just my LAN IP.How to fix that?
Attachment 112987

---

because if u try pwadmin on ur providers ip it will work too , now u should try to go to DMZ and read in tutorial what u need

Quote:

---

Originally Posted by Jacknife

because if u try pwadmin on ur providers ip it will work too , now u should try to go to DMZ and read in tutorial what u need

---

still cant enter pwadmin even with provider IP,or server IP,i forwarded ports on router and firewall made the setting like in tutorial for vbox.anyone knows why?

You will never be able to use your WAN IP from withIN your LAN (unless you purchase HIGH END commercial grade networking hardware)...

I have said this probably a thousand times now >.<

You have two options:
* Go purchase high end commercial grade networking equipment
* ONLY use LAN IP's from within your LAN, while everyone else outside your LAN utilizes your WAN

Wouldn't hurt to read THIS too (especially if you need to learn or brush up on your networking)

Quote:

---

Originally Posted by 343

You will never be able to use your WAN IP from withIN your LAN (unless you purchase HIGH END commercial grade networking hardware)...

I have said this probably a thousand times now >.<

You have two options:
* Go purchase high end commercial grade networking equipment
* ONLY use LAN IP's from within your LAN, while everyone else outside your LAN utilizes your WAN

Wouldn't hurt to read THIS too (especially if you need to learn or brush up on your networking)

---

ok,good,but still cant acces pwadmin :S.

Click Here

Hey,
supra is there anyway you can add me on skype so I can show you the problem that I am experiencing. I'm not sure where I messed up but I've tried the steps about two times and followed 343's guide on basic networking. If you can just add me on skype and help me out, it would be much appreciated! Skype Name: ayonic94
Thanks in advance!

its cool and every thing but how to change my pc adress its ***.***.100.* i want to change that 100 to 1 so i can port it because my router dont take ips except the ones that start with 192.168.1.xxx

Linux Static IP Address Configuration or Switching from a dynamic to a static IP address

its static.

guys is this thread working or not?

for me it dont work

Quote:

---

Originally Posted by 88supra86

This is a simple tutorial to get your vbox live to the net so people outside your network can play on your server

This is more directed towards Ronny1982 VBOX PWServer on hrace009 page http://forum.ragezone.com/f452/vbox-...-1-3-a-650130/

i see alot of posts about getting that live so here is a tutorial

MAKE SURE NO OTHER SYSTEM IS USING THAT IP

HAVE YOUR SERVER OFF AT THIS POINT

\\\STEP 1\\\

Put your Vbox into Bridge Mode
Select the PWServer-hrace009 system
go to Settings (gold Gear) on the start up area
Go to Network
if not already activate check "Enable Network Adapter"
Attached to "Bridged Adapter"
Name "Select the device your getting internet from"

Click the Advanced arrow

Adapter Type: "PCnet-FAST III (Am79C973)"
Mac Address: "080027AD81AD"

and make sure you have enabled "Cable Connected"

!!!!!!!!!!!!For Latest Version of VBox!!!!!!!!!!!!!!!!!!!!
there is word that you can also use NAT and enable the port forwarding that way.
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!


\\\STEP 2\\\

in your VBOX type in terminal ifconfig

Link encap:Ethernet HWaddr 08:00:27:ad:81:ad
inet addr:192.168.0.10 the rest after this doesnt matter
its the ip and the mac address you need

Now as it is a Bridged Server you need to open the ports on your firewall.

Alot of people get confused thinking its just the servers IP or the computer's IP, YOU HAVE TO PUT BOTH

example
Vbox server is 192.168.0.10
Computer running Vbox is 192.168.0.30

and add these ports 80 8080 29000 to both 192.168.0.10 AND 192.168.0.30

YOU MUST HAVE BOTH IP's registered with those ports

add those to your firewall as well

go to your Router http://192.168.0.1 enter your username and password

there is 2 ways of doing this.

DMZ your computer example 192.168.0.30 and enable the DMZ

Now Port Forward your server in your Port Forward area

if your server is not running 192.168.0.10 use the ip it provides
can sometimes be 192.168.0.51 but as i said this is for ronny1982 / hrace009 page and the ip is set to 192.168.0.10

TCP 29000 192.168.0.10 enable it
TCP 8080 192.168.0.10 enable it
TCP 80 192.168.0.10 enable it

Should work

OR you can if your router will allow you too is multiple forwards and you wont have to use DMZ

TCP 29000 192.168.0.30 enable it
TCP 8080 192.168.0.30 enable it
TCP 80 192.168.0.30 enable it
TCP 29000 192.168.0.10 enable it
TCP 8080 192.168.0.10 enable it
TCP 80 192.168.0.10 enable it


hope this makes sence to everyone i was playing around and found out how to work the VBox

IF YOUR RUNNING AN SMC ROUTER THERE IS A LITTLE MORE CHALLENGE TO GET PORT FORWARDING TO WORK

if I have missed anything let me know


ANOTHER THING... if your using canyouseeme.org to see if the ports are open, they will not show until you start the server from 192.168.0.10:8080/pwAdmin then it will become live to the net


\\\PROBLEM WITH IP, YOU CAN CHANGE IT\\\

---

is say on 8080 and 29000

I could not see your service on **.**.***.** on port (8080)
Reason: Connection refused

and

I could not see your service on **.**.***.** on port (29000)
Reason: Connection refused

why? what need i to do?

I did every thing and it still doesnt work even my ports are opened but when I get to the pw admin it doesnt work lol and my winsp also doesnt work

I did every thing u said but I cant access winscp or pwadmin or anything..

I opened port using spf[simple port forwarding]

I did the interfaces and every thing using guides so it like 90% correct.

and opened bridged mode and still cant get into the pwadmin or winscp..

please help me

Quote:

---

!!!!!!!!!!!!For Latest Version of VBox!!!!!!!!!!!!!!!!!!!!
there is word that you can also use NAT and enable the port forwarding that way.
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

---

:): Could some1 make some tutorial or guide how to setup Vbox network to NAT for this release :)
